Foshan Pailian Aluminium Ltd is one of the most reliable manufacturers and suppliers of extruded 6061 auxiliary road aluminum track profile in China. Welcome to wholesale cheap extruded 6061 auxiliary road aluminum track profile made in China here from our factory. We also accept customized orders.
Zhonglian Aluminum, a trusted ISO 9001-certified manufacturer with 33+ years of aluminum extrusion expertise, specializes in high-performance Extruded 6061 Auxiliary Road Aluminum Track Profiles. Designed for critical infrastructure projects, our profiles combine aerospace-grade alloy strength, precision engineering, and compliance with global standards like ASTM and EN.
Tired of aluminum profiles that fail under pressure?
Traditional aluminum tracks bend under heavy machinery loads, causing downtime and safety risks.
Our 6061 T6 profile features a reinforced internal rib structure and advanced extrusion technology, delivering 200 MPa compressive strength – 50% higher than standard profiles.
Zhonglian Aluminum's Extruded 6061 T6 Aluminum Track Profile solves your toughest challenges. With 33+ years of extrusion expertise and a proven track record in heavy-load industrial applications, our profiles deliver unmatched compressive strength (up to 200 MPa), tensile resistance (310 MPa yield strength), and torsional rigidity – all while reducing weight by 30% compared to steel.
Products show
Products specification
|
Parameter |
Details |
Standards/Testing |
|
Material |
6061-T6 Aluminum Alloy (Aerospace Grade) |
ASTM B221, EN 755-2 |
|
Tensile Strength |
≥290 MPa |
ASTM E8 |
|
Yield Strength |
≥240 MPa |
ASTM E8 |
|
Compressive Strength |
350 MPa (Tested under axial load) |
ASTM E9 |
|
Torsional Resistance |
Optimized cross-section resists twisting (15° max deflection at 500 N·m) |
Custom FEA Simulation |
|
Density |
2.7 g/cm³ |
ISO 1183 |
|
Surface Treatment |
Optional: Anodizing (15–25μm), Powder Coating (60–120μm), Sandblasting |
MIL-A-8625, AAMA 2604 |
|
Corrosion Resistance |
1,500+ hours salt spray resistance (coated) |
ASTM B117 |
|
Dimensional Tolerance |
±0.1mm (Profile), ±0.02mm (CNC Machined Features) |
ISO 2768 |
|
Standard Length |
5.8m, 6m (Custom lengths up to 12m available) |
– |
|
Weight |
~2.5 kg/m (Varies by profile design) |
– |
|
Operating Temperature |
-50°C to +150°C |
– |
|
Certifications |
ISO 9001, ISO 14001, RoHS Compliant |
Third-party audited |
|
Applications |
Road barriers, traffic guide rails, pedestrian safety systems, parking tracks |
– |
Products features
Exceptional Mechanical Strength
Compressive Strength
Our 6061 aluminum track profile exhibits outstanding compressive strength. Through advanced extrusion techniques and strict quality control, it can withstand significant vertical loads without deformation. In fact, it has been tested to endure pressures up to [X] MPa, ensuring reliable performance in demanding environments where heavy loads are applied from above.
Tensile Strength
With a high - quality alloy composition and optimized manufacturing process, the profile boasts remarkable tensile strength. It can resist stretching forces, preventing breakage under tension. Our in - house tests have shown that it can handle tensile forces of up to [X] MPa, making it suitable for applications where the material needs to bear pulling loads, such as in mechanical structures and transportation systems.
Torsional Resistance
The design and structure of our 6061 aluminum track profile also provide excellent torsional resistance. When subjected to twisting forces, it maintains its structural integrity, minimizing the risk of warping or failure. This feature is crucial for applications where rotational forces are present, like in industrial machinery and equipment components.
Design Flexibility & Structural Engineering Expertise
As one of China's few aluminum extrusion factories offering certified mechanical design services, Zhonglian Aluminum provides:
- Custom Structural Analysis: Finite Element Analysis (FEA) to optimize load distribution and reduce material waste.
- Tailored Cross-Sections: Modify wall thickness, rib placement, or hollow sections for specific stress requirements.
- Prototyping Support: 3D mockups and sample testing to validate performance before mass production.
Precision CNC Deep Machining
Our comprehensive one - stop service includes advanced CNC deep processing. Using high - precision CNC machines, we can perform a wide range of operations on the aluminum track profile, such as milling, drilling, turning, and threading. This allows us to create complex shapes and precise features according to your specifications. Whether you require holes for assembly, slots for fittings, or intricate contours, our CNC processing capabilities ensure that the final product is of the highest quality and meets your exact needs.
Surface Treatment
To enhance the appearance and performance of our Extruded 6061 Auxiliary Road Aluminum Track Profile, we offer a variety of surface treatment options.
- Anodizing (Type II/III): 15–25μm thickness, corrosion-resistant, available in clear/black/gold.
- Powder Coating: 60–120μm epoxy-polyester layers, RAL color matching, UV-resistant.
- Mechanical Finishes: Brushed, polished, or sandblasted textures.
Rigorous Quality Control
Every batch undergoes 5-stage inspection:
- Material Certification: Verify 6061-T6 alloy composition via spectrometry.
- Mechanical Testing: Tensile, compression, and torsion tests (ASTM E8/E9 compliant).
- Dimensional Checks: CMM (Coordinate Measuring Machine) for profile accuracy.
- Coating Adhesion Tests: Cross-cut testing per ISO 2409.
- Salt Spray Testing: 1,500+ hours (ASTM B117) to validate corrosion resistance.
Packaging Method
We understand the importance of proper packaging to ensure the safe transportation and storage of our products. Our Extruded 6061 Auxiliary Road Aluminum Track Profile is carefully packaged using high - quality materials. Each profile is wrapped with protective films to prevent scratches and damage during transit. For larger orders, they are then bundled securely and placed in wooden crates or custom - made packaging boxes, which are designed to withstand the rigors of international shipping. This ensures that the products reach you in perfect condition, ready for immediate use.
our service
At Zhonglian Aluminum, we are committed to providing excellent customer service. Our dedicated sales and technical teams are always available to answer your inquiries, offer technical support, and guide you through the entire process, from product selection to after - sales service. We also offer fast and reliable delivery options, working with trusted logistics partners to ensure that your orders are shipped promptly and arrive on time. In addition, we provide after - sales support, addressing any issues or concerns you may have with our products.
customers reviews
Our commitment to quality and service has earned us rave reviews from customers around the world. Over the years, we have built long - term partnerships with numerous international clients in various industries. They have commended our high - quality products, timely delivery, and professional service. Many customers have also praised our ability to provide customized solutions, which has helped them achieve their project goals efficiently. Our satisfied customers' testimonials and repeat business are a testament to our excellence in the aluminum manufacturing industry.
Why Partner With Zhonglian Aluminum?
✅ 33+ Years of Innovation: Advanced 1,800T–3,600T extrusion presses for complex profiles.
✅ End-to-End Solutions: From mold design (7–15 day lead time) to final machining.
✅ Global Client Trust: Used in over 500 road projects across 30+ countries.
✅ Cost Efficiency: Factory-direct pricing, 15% lower than industry averages.
Call to Action
Know more Structural Calculation? Please download our Free Auxiliary Road Aluminum Track Structural Calculation Sheet or request a Custom Quotation within 24 hours! Contact us at zhlaluminum@gmail.com or +86-18825985370 to start your project.
